MC 930 - Stereo Set. True Condenser Microphones

MC 930 – Stereo Set. True Condenser Microphones – Made in Germany

Updated 2023 iteration:

Hint# Looking to Mic up a drum kit?
Then check out our 6 part video series on drum miking, we explain what to look for and which mic is best for which instrument.

The MC 930 Stereo Set stereo can be used to create professional stereo recordings in XY or ORTF configuration. The delivery includes two elastic suspensions including two microphone clamps and two wind shields - so the stereo set can be used straight away.

The individual MC 930 is a flexible true condenser microphone with switchable -15 dB attenuation and low-cut filter. If you appreciate the clear sound and high impulse fidelity of small-diaphragm condenser microphones, the MC 930 is the right choice for you. It covers a wide range of application scenarios in the studio and on stage due to its compact design and the authentic and detailed sound character, whereby all post-processing options are also open.

Whether for acoustic guitar, piano, hihat, overheads, choir, orchestra, voice or solo instruments of any kind, there is almost no sound source where the MC 930 is not convincing.  For speech and vocal recordings from a short distance as well as for outdoor recordings, we recommend the WS 101 wind shield.

Above all, its natural sound reproduction is appreciated by users. Equipped with a switchable pre-damping and a switchable low-cut, the MC 930 also impresses with remarkable technical features.

Like all microphones of the M series, the MC 930 is also elaborately handmade at our factory in Heilbronn, Germany.

FEATURES

• Flexible true condenser microphones with cardioid polar pattern
• Switchable pre-attenuation (-15dB) and low-cut filter
• High impulse fidelity and good transient response
• High sensitivity and excellent transient response
• Particularly natural treble reproduction
• Outstanding clear and detailed sound
• Manufactured by hand in Germany

SPECIFICATIONS (PER MICROPHONE)

• Transducer type: True condenser
• Operating principle: Pressure gradient
• Frequency response: 40 - 20,000 Hz
• Polar pattern: Cardioid
• Sensitivity(0 dB = 1 V/Pa): 30 mV/Pa (= -30.5 dBV)
• Nominal impedance: 180 Ω
• Load impedance: 1000 Ω
• Max. SPL at 1 kHz: 125 dB
• Max. SPL with pre-attenuation: 140 dB
• Signal-to-noise ratio rel. to 1 Pa:  71 dB
• A-weighted equivalent SPL: 16dB
• Low-cut filter: switchable, 6 dB/octave at 250 Hz
• Power supply: 11 - 52 V phantom power
• Current consumption: 4.6 mA
• Connection:  3-pin XLR, male


DIMENSIONS (PER MICROPHONE)

• Length: 128 mm
• Diameter: 21 mm
• Weight: 106 g

VARIANTS
1 x MC 930 True condenser microphone
Supplied with MA-CL 21 microphone clamp. . . . . . . . . . . . . . Order # 730.211

Soft protective storage case to protect your investment.

OPTIONAL ACCESSORIES
EA 19/25 Elastic suspension 19 - 25 mm, incl. MA-CL 36
microphone clamp:  Order # 407.194

MA-CL 21 Microphone clamp:  Order # 727.946

WS 101 Wind shield, charcoal-grey: Order # 111.244
